| ชื่อแบรนด์: | AIKE POWER |
| เลขรุ่น: | AC625 |
| MOQ: | 1 |
| ราคา: | USD |
| Payment Terms: | l/c, t/t |
| ความสามารถในการจําหน่าย: | 1,000 ชุด/ม. |
| Generator Set | ||
|---|---|---|
| Genset Model | AC625 | |
| Rating Power (KW/KVA) | 450/562.5 | |
| Standby Power(KW/KVA) | 500/625 | |
| Rating Ammeter(A) | 812 | |
| Diesel Engine | ||
| Engine model | KTAA19-G5 | |
| Prime Power(KW/KVA) | 470/639 | |
| Standby Power(KW/KVA) | 555/754 | |
| Number of Cylinder & Configuration | 6 cylinders in line | |
| Bore X Stroke (mm) | 159X159 | |
| Displacement(l) | 19 | |
| Compression Ratio | 13.9:1 | |
| Governor type | Electronic governor | |
| Rated RPM | 1500 | |
| Exhaust System | ||
| Exhaust gas flow(m³/min) | 103.2 | |
| Max. Exhaust Gas Temperature(℃) | 450 | |
| Max. Exhaust back Pressure(KPA) | 10 | |
| Air Intake System | ||
| Aspiration Type | Turbo & Air-Air cooled | |
| Max. intake depression(mbar) | 6 | |
| Combustion air Volume(m³/min) | 40.3 | |
| Fuel System | ||
| Rating Fuel Consumption(l/h) | 117 | |
| 75% full Fuel Consumption(l/h) | 119 | |
| Lubrication System | ||
| Total oil capacity(l) | 50 | |
| Max permissible oil temp(℃) | 121 | |
| Oil pressure at rated rpm(KPA) | 241-345 | |
| Cooling System | ||
| Total Coolant capacity(l) | 91 | |
| Max. temperature of coolant(℃) | 100 | |
| Fan cooling air flow (m³/min) | 735 | |
| Alternator | ||
| Alternator model | HCI544C | |
| Rating Voltage(V) | 400/230 | |
| Rating Capacity(KW/KVA) | 480/600 | |
| Eff.% | 93.8% | |
| Power Factor | 0.8 | |
| Exciting type | Brushless self-exciter, AVR | |
| Voltage regulation | ±0.5% | |
| No. of Phase | 3 phase 4 wire | |
| Enclosure Class | IP23 | |
| Class of Insulation | H | |
| Battery | ||
| Rating Capacity(AH) | 2X200AH 12V | |
| Dimensions & Weight | ||
| Generator set dimension (LXWXH) | 3750x1500x1900 | |
| Generator set Net Weight (kg) | 5000 | |
